Name: Custom LCD Display for Thermometer And Hygrometer Zebra Connector Tn Segment Lcd 1/3 BIAS TN Positive Transflective Type LCD
Brand: HongKong Guanke Industrial Limited
SKU: FTP4546FS01
Price: 3.10 USD
Availability: InStock

Rumah > Produk > Layar LCD TN >

Custom LCD Display for Thermometer And Hygrometer Zebra Connector Tn Segment Lcd 1/3 BIAS TN Positive Transflective Type LCD

Custom TN LCD display for thermometer

Zebra connector TN segment LCD

Transflective LCD with 1/3 BIAS

Tempat asal:

Dongguan, Cina

Nama merek:

Fangsheng

Sertifikasi:

ISO9001:2015,IATF16949,RoHS,Reach,etc

Nomor model:

FTP4546FS01

Hubungi Kami

Minta Kutipan

Custom LCD Display for Thermometer And Hygrometer Zebra Connector Tn Segment Lcd 1/3 BIAS TN Positive Transflective Type LCD

Rincian produk

Nama Produk:

Layar LCD Kustom untuk Termometer dan Higrometer Konektor Zebra Segmen Tn Lcd 1/3 BIAS TN LCD Tipe T

Tipe Tampilan:

TN, LCD positif

Tipe Konektor:

Zebra (disesuaikan)

Suhu Operasional:

-0°c Hingga +50°c

Suhu Penyimpanan:

-10°C hingga +60°C

Frekuensi bingkai:

64Hz

Menyoroti:

Custom TN LCD display for thermometer

Zebra connector TN segment LCD

Transflective LCD with 1/3 BIAS

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1000

Harga

$0.1-$8

Kemasan rincian

Tas Bubble + Blister + Kotak Busa + Karton

Waktu pengiriman

25-30 hari

Syarat-syarat pembayaran

L/C, D/A, D/P, T/T, Western Union, Moneygram,

Menyediakan kemampuan

Set / bulan 200k

Produk terkait

+86 136 3170 3190

fssales03@fsdzlcd.com

86-769-2270-5825

Hubungi Sekarang

Deskripsi Produk

Custom LCD Display for Thermometer And Hygrometer

Custom LCD display featuring Zebra connector, TN segment LCD with 1/3 BIAS, TN positive transflective type technology. Designed specifically for thermometer and hygrometer applications.

Technical Specifications

Parameter	Value
DISPLAY MODE	TN, POSITIVE MODE
DRIVE CONDITION	1/4 DUTY, 1/3 BIAS
VIEWING DIRECTION	6 O'CLOCK
OPERATING TEMP	-0°C to +50°C
STORAGE TEMP	-10°C to +60°C
OPERATING VOLTAGE	4.5V
FRAME FREQUENCY	64Hz
FRONT POLARIZER	TRANSMISSIVE, ADHESIVE
BACK POLARIZER	TRANSFLECTIVE, ADHESIVE
CONNECTORS	ZEBRA
